Merlin Commander Extreme MS125MYQ

| Write a review
☑ Delivery Available

Yes, this item is available for delivery.

Metro: Arrives in 2 - 5 business days after dispatch.
Regional: Arrives in 3 - 10 business days after dispatch.

Please Note: Due to public holidays, deliveries may take additional time from estimates displayed above.

Time frames shown are subject to change, cut-off times are based off of AEST.

  • Commander Extreme MS125MYQ


    NOTE: This sectional opener is not appropriate for Tilt Doors, only Sectional.


    This Product Includes:

    • 2 x  Four Button Remote Control (Security+ 2.0 & Security+) (E970M)
    • Four Button Wireless Wall Mount Remote Control  (Security+ 2.0) (E148M)


    Product Features:

    • MYQ COMPATIBLE TECHNOLOGY lets users create schedules, monitor, receive alerts and control the garage door opener away from home.1
    • SOFT-START AND SOFT-STOP for smooth operation.
    • QUIET DC MOTOR eliminates noise and vibrations through the ceiling and provides smooth operation.
    • BATTERY BACKUP ensures access even when the power is out.2
    • HEAVY-LIFTING POWER operates doors up to 150 kgs/ 286kg. 3
    • SECURITY+ 2.0® sends a new code with every remote click.
    • PREMIUM AUTOMATIC SAFETY REVERSE function will allow your garage door to stop and reverse automatically if obstructed going down or stop going up.
    • TIMER-TO-CLOSE automatically closes the door after a pre-set amount of time.4
    • IMPROVED TRANSMITTER RANGE has up to 18% better range meaning you can start opening your garage door sooner.5
    • AUTOMATIC FORCE SENSING monitors and adjusts the force needed to open your garage with each operation.
    • MANUAL RELEASE CORD allows you to open your garage door whenever needed.

    1 Additional purchase of Merlin myQ Gateway and Safety IR Beam accessories is required to enable myQ functionality.
    2 Additional purchases of Merlin Battery Backup accessory are required to enable Battery Backup functionality
    3 286 kg door rating is based on having the installation of Safety IR Beams.
    4 Safety IR Beams must be installed to enable the use of Timer-to-Close. See User Guide for additional information. Smartphones are not included.
    5 When compared to other available Merlin products.




    • 24V DC motor with thermal overload protection
    • Input voltage: 240V AC
    • Rated door area up to 20m²
    • Max door weight: up to 150kg / 286kg (with beams installed)
    • Max peak pulling force: 1200 N
    • C-rail with chain drive
    • 433.92, 433.30, 434.54 MHz AM radio with Chamberlain Security + 2.0 rolling code technology
    • Up to 64 memory registers
    • Courtesy light: Powerful LED Lighting
    • Min headroom required: 30mm
    • Maximum lifting under spring tension = 20kg
    • Suitable for steel and timber spring balanced doors
    • Door opening time: 18 -22 seconds
    • Door closing time: 21 -31 seconds
    • Based on a 2.4m high door
    • Door height: 3.5m
    • Door width: 5.7m
    • Double dwelling


      Safety Features:

      Premium Automatic Safety Reverse

      • With its automatic safety function, your garage door will stop and reverse automatically if obstructed going down or stop going up.

      Automatic Force Sensing

      • Equipped with automatic force sensing, with each operation the garage door opener monitors and adjusts the force needed to open your garage door.

      Manual Release

      • In case of power failure, you can simply activate the manual release to open your garage door.



        The product includes wireless transmitters and wall controls that contain coin/button cell batteries.
        Keep wireless devices and batteries away from children.
        The battery can cause severe or fatal injuries in 2 hours or less if swallowed or placed inside any part of the body.
        Seek immediate medical attention if it is suspected that a coin/button cell battery has been swallowed or placed inside any part of the body.
